　　The U.S.-gauge socket is one of the U.S.standards for power outlets,which is based on the standards set by the National Electrical Manufacturers Association(NEMA)to provide a means of power output for use within the United States.The voltage and current ratings of U.S.-gauge outlets are very important technical indicators that affect the stability and reliability of outlets and plugs when in use.The following is a detailed description of the rated voltage and current of the U.S.-gauge sockets.

　　I.NEMA 5 Series Receptacles

　　NEMA 5 series sockets(5-15,5-20 and 5-30)are common types of U.S.gauge sockets.They are all three-pin plug sockets with two phase pins and a ground pin.The NEMA 5-15 receptacle is rated at 125 volts(V)and 15 amps(A),while the NEMA 5-20 and NEMA 5-30 receptacles are rated at 125V/20A and 125V/30A,respectively.These receptacles are commonly used in home appliances,office appliances,and light industrial applications.

　　II.NEMA 6 Series Receptacles

　　NEMA 6 series receptacles(6-15,6-20,and 6-30)are U.S.-gauge receptacles for high power applications.These receptacles have a four-pin plug consisting of two phase line pins,a neutral pin,and a ground pin.The NEMA 6-15 receptacle is rated at 250 V and 15 A.The NEMA 6-20 receptacle is rated at 250 V and 20 A.The NEMA 6-30 receptacle is rated at 250 V and 30 A.These receptacles are commonly used in high power tools and equipment,manufacturing,and heavy industrial applications.

　　NEMA 14 Series Receptacles

　　NEMA 14 series receptacles(14-20,14-30,and 14-50)are also one of the U.S.-gauge receptacles used in high-power applications.These receptacles also have a four-pin plug consisting of two phase line pins,a neutral pin,and a ground pin.Among them,NEMA 14-20 receptacles are rated at 125/250V,20A,three-phase;NEMA 14-30 receptacles are rated at 125/250V,30A,three-phase;and NEMA 14-50 receptacles are rated at 125/250V,50A,three-phase,and they are commonly used for electric vehicle charging and critical industrial applications.

　　Overall,the voltage and current ratings of American Standard sockets are important technical specifications for sockets and plugs,and they determine the reliability and stability of the sockets when in use.We need to choose the right type of socket,wire it accurately and use it according to the design of the plug and the power requirements of the device when using the socket.Only in this way can we ensure the stability of electrical appliances and ensure our reliable ground.
